Dynamic SVG
About Air Handling Unit
Air Handling Unit is a Dynamic SVG that depicts a closed air handling unit casing as a calm, brushed-steel product render. Three closed access doors sit side by side on a plinth, and each door carries a round sight glass, so the equipment is recognized at a glance on a process screen. The artwork is static and shows the unit only, without ducts, dampers, labels or status indicators.
Key Features
- Three closed access doors: Each door has hinges, a lever handle and a seal line arranged in a regular left-to-right rhythm.
- Sight glass per door: Each porthole reveals the component inside its section: a filter bank, a fan and a coil.
- Premium steel rendering: Vertical casing gradients, diagonal door shading and top-edge highlights give the unit real depth.
- Transparent background: No backing plate, so the unit blends into any screen layout.
Customization
The control exposes five properties that you configure in the engineering tool and bind to PLC tags or local values:
- BasicColor (HmiColor): Sets the base color of the SVG element.
- FanRotation (number): Rotates the fan component seen through the second sight glass.
- FanColor (HmiColor): Sets the stroke color of the fan silhouette.
- FilterColor (HmiColor): Sets the stroke color of the filter silhouette.
- CoilColor (HmiColor): Sets the stroke color of the coil silhouette.
Use Cases
Ideal for HVAC process pages, plant overview displays, control room walls and operator panels where an air handling unit must be identified quickly and matched to its live data.
Compatibility
Works with WinCC Unified and WinCC V8. Import the .svghmi file into your project, place it on a screen and bind the five properties to your tags.
AI-Generated: This dynamic SVG was automatically generated using AI. Please test and validate it thoroughly before deploying in production environments.
⚠️ AI-Generated: This dynamic svg was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.
## Current version: v1 (2026-10-19)0 Reviews
