<p><em>Bring Your 3D Models to Life in WinCC Unified</em></p><p>The <strong>Digital Twin Custom Web Control</strong> is a powerful visualization tool designed to seamlessly integrate 3D models into SIMATIC WinCC Unified systems. With this control, users can create fully interactive digital twins that enhance monitoring, diagnostics, and user experience in SCADA environments.</p><p><strong>Key Features:</strong></p><ul><li><strong>3D Viewer Integration:</strong> View complex 3D models directly within WinCC Unified runtime.</li><li><strong>Interactive Dynamics:</strong> Change colors, show or hide objects, and move components of the 3D model based on live process data.</li><li><strong>User Interaction:</strong> Enable actions by clicking directly on parts of the 3D model, such as opening pop-ups or triggering system functions.</li><li><strong>Dark Mode:</strong> Optimize visibility with a built-in night mode.</li><li><strong>Developer Mode:</strong> Gain insight into model structure to easily configure dynamic behaviors.</li></ul><p>This solution is ideal for industries looking to visualize real-time data through intuitive, animated 3D interfaces—enhancing both operational insight and user engagement.</p><p><br></p><p>The item includes:</p><ul><li>Custom Web Control</li><li>Instructions to make it work</li><li>Demonstration video</li><li>Demo project and instructions to make it work</li></ul>

Digital Twin & 3D Viewer | Custom Web Control | WinCC Unified

SIEMENS - SIMATIC

<h3>Custom Web Control</h3>
<p><h3>About Circular Analog Gauge</h3><p>The Circular Analog Gauge is a high-performance Custom Web Control designed for modern industrial SCADA and HMI environments. It provides a sophisticated process monitoring interface featuring a rotating needle across a calibrated 240-degree scale, combining the intuitive readability of traditional instrumentation with the precision of digital readouts. Designed for seamless integration, it allows engineers to visualize critical process data within WinCC Unified and WinCC V8 environments with professional-grade aesthetics.</p><h3>Key Features</h3><ul><li><strong>Dynamic Visualization:</strong> A smooth-motion needle tracks the <strong>value</strong> property in real-time, providing immediate visual feedback of process trends.</li><li><strong>Intelligent Alerting:</strong> Built-in logic triggers the <strong>ThresholdExceeded</strong> event when the process crosses defined boundaries, enabling proactive operator response.</li><li><strong>High-Contrast Readout:</strong> Features a tabular digital display with a customizable <strong>unit</strong> string for unambiguous data interpretation at a distance.</li><li><strong>Advanced Interactivity:</strong> Supports programmatic control via the <strong>setValue</strong> and <strong>resetLimits</strong> methods for automated dashboard behaviors.</li></ul><h3>Customization</h3><p>The control offers 10 bindable properties for complete visual and functional alignment with your project standards. Engineers can define the operational range using <strong>minValue</strong> and <strong>maxValue</strong>, and configure safety boundaries via <strong>warnThreshold</strong> and <strong>alarmThreshold</strong>. The visual identity is fully adjustable through properties such as <strong>backgroundColor</strong>, <strong>safeZoneColor</strong>, <strong>warnZoneColor</strong>, and <strong>alarmZoneColor</strong>, ensuring the gauge fits perfectly into any dark or light mode industrial theme.</p><h3>Use Cases</h3><ul><li><strong>Pressure &amp; Flow Monitoring:</strong> Ideal for displaying pipeline pressure or flow rates where rapid detection of limit excursions is critical.</li><li><strong>Energy Management:</strong> Visualizing power loads and current consumption with clear warning and alarm zones.</li><li><strong>Machine Health:</strong> Monitoring motor RPM or temperature levels on local operator panels.</li></ul><h3>Compatibility</h3><p>Fully compatible with <strong>WinCC Unified (TIA Portal) and WinCC V8</strong>. The control is optimized for high-resolution industrial displays and supports standard HMI tag binding for all dynamic properties.</p><p>💡 <strong>TIA Portal Reminder:</strong> Remember to uncheck the &quot;Read only&quot; option in TIA Portal when linking a tag to a property that needs to be written from the Custom Web Control. If you do not, the CWC will only be able to read the HMI tags and not write to them.</p><p>⚠️ <strong>AI-Generated:</strong> This custom web control was automatically generated using AI. Please test and validate before deploying in production environments.</p></p>
<p>⚠️ <strong>AI-Generated:</strong> This custom web control was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.</p>


## Current version: v1 (2026-09-22)

Circular Analog Gauge | Custom Web Control | WinCC Unified & V8

<h3>Dynamic SVG</h3><h3>About Plate Heat Exchanger</h3><p>Plate Heat Exchanger is an interactive industrial graphic component. Designed for modern SCADA and HMI screens, it connects directly to your PLC tags for instant real-time updates. Ideal for process monitoring and control screens.</p><h3>What You Can Configure</h3><p>With <strong>6 configurable properties</strong>, operators can change basic, medium1 inlet, medium1 outlet colors to indicate equipment state, adjust numeric parameters for position, scale, or other visual aspects. All properties are directly bindable to PLC tags in TIA Portal — no coding required.</p><h3>Compatibility</h3><p>Works with <strong>WinCC Unified</strong> and <strong>WinCC V8</strong>. Simply drop the .svghmi file into your project and start configuring.</p><p>⚠️ <strong>AI-Generated:</strong> This dynamic SVG was automatically generated using AI. Please test and validate before deploying in production environments.</p><p>⚠️ <strong>AI-Generated:</strong> This dynamic svg was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.</p><p> ## Current version: v1 (2026-09-10) </p>

Plate Heat Exchanger | Dynamic SVG | WinCC Unified & V8

<h3>Dynamic SVG</h3>
<p><h3>About Industrial Mixer Tank</h3><p>The Industrial Mixer Tank is a high-performance Dynamic SVG engineered for modern SCADA and HMI environments. It provides a sophisticated visual representation of mixing vessels, allowing control engineers to deliver intuitive, real-time process monitoring for WinCC Unified and WinCC V8 platforms without the overhead of heavy graphical assets.</p><h3>Key Features</h3><ul><li><strong>Dynamic Agitation:</strong> Visualize mechanical movement through the AgitatorAngle property, providing immediate visual feedback of motor operation.</li><li><strong>Precise Level Tracking:</strong> The FillLevel property enables accurate representation of vessel contents, scaling seamlessly with your process data.</li><li><strong>Integrated Motor Status:</strong> A dedicated MotorStatusColor property allows for instant identification of equipment health, such as running, stopped, or faulted states.</li></ul><h3>Customization</h3><p>This component offers 6 distinct properties for deep integration. Engineers can define the <strong>BasicColor</strong> to match plant standards, adjust the <strong>LiquidColor</strong> to represent different media, and toggle the <strong>AgitatorVisible</strong> boolean to switch between static storage and active mixing configurations. Every property is designed for direct binding to PLC tags, ensuring a code-free implementation.</p><h3>Use Cases</h3><ul><li><strong>Chemical Processing:</strong> Monitor blending cycles and reagent levels in real-time.</li><li><strong>Food & Beverage:</strong> Visualize batch mixing and storage status on operator panels.</li><li><strong>Water Treatment:</strong> Track flocculation and sedimentation processes with clear visual indicators.</li></ul><h3>Compatibility</h3><p>Fully optimized for <strong>WinCC Unified and WinCC V8</strong>. This Dynamic SVG follows the hmi-bind standard, ensuring high-performance rendering and crisp scaling on any industrial display resolution.</p><p><strong>AI-Generated:</strong> This dynamic svg was automatically generated using AI. Please test and validate all property bindings and visual behaviors before deploying in production environments.</p></p>
<p>⚠️ <strong>AI-Generated:</strong> This dynamic svg was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.</p>


## Current version: v1 (2026-09-25)

Industrial Mixer Tank | Dynamic SVG | WinCC Unified & V8

<h3>Dynamic SVG</h3><h3>About Process Gauge 270</h3><p>The Process Gauge 270 is a premium Dynamic SVG component engineered for high-precision industrial monitoring within WinCC Unified and WinCC V8 environments. Featuring a wide 270-degree sweep, this instrument provides superior resolution for critical process variables compared to standard semi-circular gauges. Its sophisticated design mimics high-end control room hardware, utilizing multi-layered metallic bezels and a deep-contrast dial face to ensure maximum legibility at a distance.</p><h3>Key Features</h3><ul><li><strong>High-Resolution 270° Arc:</strong> Offers an expanded visual range from 135° to 405°, allowing for smoother needle transitions and more precise readings.</li><li><strong>Industrial Aesthetics:</strong> Features a brushed stainless steel bezel with directional light reflections and a modern dark-mode dial face.</li><li><strong>Dynamic Needle Response:</strong> A high-visibility safety-red indicator with a realistic hub cap and integrated drop-shadow for enhanced depth perception.</li><li><strong>Vector Scalability:</strong> Built as a pure SVG, the gauge maintains crisp lines and professional quality at any resolution, from mobile panels to large control room displays.</li></ul><h3>Customization</h3><p>Engineers can fully tailor the gauge to specific process requirements through six integrated properties. The <strong>TrackOffset</strong> property allows for precise needle positioning based on the process variable, while <strong>DialColor</strong> and <strong>BasicColor</strong> enable alignment with corporate design standards. The scale visibility can be refined using <strong>MajorTicksColor</strong> and <strong>TrackBackgroundColor</strong>, and the optional <strong>ShowGlare</strong> boolean toggles a realistic glass reflection overlay for added realism.</p><h3>Use Cases</h3><ul><li><strong>Pressure and Flow Monitoring:</strong> Ideal for systems requiring a wide measurement range, such as 500 to 2000 units.</li><li><strong>Power Generation:</strong> Visualizing turbine speeds or electrical loads where precision is paramount.</li><li><strong>Chemical Processing:</strong> Monitoring reactor levels or temperatures with clear, high-contrast instrumentation.</li></ul><h3>Compatibility</h3><p>This component is fully compatible with <strong>WinCC Unified and WinCC V8</strong>. It is delivered as a standard .svghmi file, ready for immediate tag binding and deployment without additional scripting.</p><p><strong>AI-Generated:</strong> This dynamic SVG was automatically generated using AI technology. Please ensure thorough testing and validation in a staging environment before deploying it in live production or safety-critical systems.</p><p>⚠️ <strong>AI-Generated:</strong> This dynamic svg was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.</p>

Process Gauge 270 | Dynamic SVG | WinCC Unified & V8

<h3>Dynamic SVG</h3>
<p><h3>About Process Agitator Tank</h3><p>The Process Agitator Tank is a high-performance Dynamic SVG component specifically engineered for modern industrial SCADA and HMI environments. This visual asset provides a clear, intuitive representation of mixing vessels, allowing operators to monitor critical process variables at a glance within their WinCC Unified or WinCC V8 applications.</p><h3>Key Features</h3><ul><li><strong>Dynamic Visualization:</strong> Features a high-fidelity SVG design that maintains clarity at any scale, from small operator panels to large control room displays.</li><li><strong>Seamless Integration:</strong> Designed for native compatibility with Siemens TIA Portal and WinCC environments, requiring zero custom scripting for basic operation.</li><li><strong>Real-Time Feedback:</strong> Optimized for low-latency updates, ensuring that the visual state of the tank accurately reflects the physical process conditions in the field.</li></ul><h3>Customization</h3><p>The control offers three primary properties that can be bound directly to PLC tags or internal HMI variables:</p><ul><li><strong>BasicColor:</strong> Define the primary aesthetic of the tank structure to match your corporate design standards or specific equipment types.</li><li><strong>LiquidLevel:</strong> Dynamically adjust the vertical transform of the internal liquid graphic to represent volume or fill percentage.</li><li><strong>LiquidColor:</strong> Change the fill color of the liquid to indicate different media types, chemical states, or alarm conditions.</li></ul><h3>Use Cases</h3><p>This component is ideal for chemical processing plants, food and beverage production lines, water treatment facilities, and pharmaceutical manufacturing where monitoring agitation and storage levels is critical for operational safety and efficiency.</p><h3>Compatibility</h3><p>The Process Agitator Tank is fully compatible with <strong>WinCC Unified (PC and Unified Comfort Panels) and WinCC V8</strong>. It follows the standard SVGHMI format for easy drag-and-drop implementation.</p><p><strong>Note:</strong> This dynamic SVG was automatically generated using AI. Please ensure you perform thorough functional testing and validation within your specific engineering environment before deploying this component in a live production system.</p></p>
<p>⚠️ <strong>AI-Generated:</strong> This dynamic svg was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.</p>

Process Agitator Tank | Dynamic SVG | WinCC Unified & V8

<h3>Dynamic SVG</h3>
<p><h3>About Globe Valve Symbol</h3><p>The Globe Valve Symbol is a high-performance Dynamic SVG designed specifically for industrial SCADA and HMI environments. This component provides a professional P&amp;ID representation of a globe valve, featuring two opposing triangles meeting at a central vertex, horizontal pipe stubs, and a vertical stem topped with a manual handwheel. It is engineered to provide clear, immediate visual feedback of process states in complex piping and instrumentation diagrams.</p><h3>Key Features</h3><ul><li><strong>ISA 5.1 Compliant Design:</strong> Follows standard schematic conventions for universal recognition by process engineers and operators.</li><li><strong>Dynamic Visual Feedback:</strong> The valve body is grouped to allow for instantaneous color changes, representing open, closed, or fault conditions.</li><li><strong>High-Quality Rendering:</strong> Utilizes a sophisticated 3-stop linear gradient to provide a modern metallic finish that enhances the visual depth of the HMI screen.</li><li><strong>Vector Scalability:</strong> Built with a 100x100 viewBox to ensure crisp rendering at any size without pixelation.</li></ul><h3>Customization</h3><p>The symbol is fully integrated with the WinCC environment through the <strong>BasicColor</strong> property. This property allows engineers to bind the valve's fill color directly to PLC tags or internal HMI tags, enabling the component to shift between Green (Open), Red (Closed), and Amber (Fault) based on real-time field data.</p><h3>Use Cases</h3><p>This dynamic symbol is ideal for process monitoring dashboards in water treatment facilities, chemical processing plants, and oil and gas distribution systems. It is perfectly suited for control room displays where clear valve status identification is critical for operational safety.</p><h3>Compatibility</h3><p>Fully compatible with <strong>WinCC Unified and WinCC V8</strong>. The component is delivered as a standard .svghmi file, allowing for a seamless drag-and-drop workflow within your engineering environment.</p><p><strong>Disclaimer:</strong> This dynamic SVG was automatically generated using AI technology. Please ensure thorough testing and validation within your specific project environment before deploying in a live production system.</p></p>
<p>⚠️ <strong>AI-Generated:</strong> This dynamic svg was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.</p>

Globe Valve Symbol | Dynamic SVG | WinCC Unified & V8

<h3>Custom Web Control</h3><h3>About Power Monitor Dashboard</h3><p>The Power Monitor Dashboard is a professional-grade Custom Web Control designed for comprehensive electrical monitoring in industrial SCADA environments. It provides a centralized interface for 3-phase power analysis, combining real-time numerical data with dynamic trend visualization to ensure optimal energy management and system health.</p><h3>Key Features</h3><ul><li><strong>3-Phase Analysis:</strong> Monitor voltage (L1, L2, L3) and current (L1, L2, L3) across all phases with dedicated gauges and high-precision readouts.</li><li><strong>Power Metrics:</strong> Real-time calculation and display of Active Power (kW), Reactive Power (kVAr), Apparent Power (kVA), Power Factor, and Frequency.</li><li><strong>Dynamic Trending:</strong> Integrated trend chart with configurable time ranges, auto-scaling Y-axis, and limit line overlays for historical data analysis.</li><li><strong>Event Intelligence:</strong> Built-in logic to fire events such as PowerLimitExceeded and PhaseImbalanceDetected for immediate operator notification.</li></ul><h3>Customization</h3><p>The control offers 34 adjustable properties for seamless integration. Users can define scale maximums via voltageMax and currentMax, customize all interface text using labels like labelVoltage and labelTrend, and adjust visual aesthetics through backgroundColor and specific font size settings for gauges and summaries. The trend chart is highly flexible, allowing for grid toggling and manual Y-axis range definitions.</p><h3>Use Cases</h3><p>Perfect for energy management systems (EMS), motor control centers, substation monitoring, and any industrial facility requiring precise oversight of electrical distribution and consumption patterns.</p><h3>Compatibility</h3><p>Fully compatible with <strong>WinCC Unified (TIA Portal) and WinCC V8</strong>. The control supports bidirectional data binding for all numerical and configuration properties.</p><p>💡 <strong>TIA Portal Reminder:</strong> Ensure the "Read only" option is unchecked in TIA Portal when linking tags to properties that require write access from the control. This is essential for methods like resetTrend to function correctly within the HMI runtime.</p><p>⚠️ <strong>AI-Generated:</strong> This custom web control was automatically generated using AI. Please perform thorough testing and validation in a staging environment before deploying to production systems.</p><p>⚠️ <strong>AI-Generated:</strong> This custom web control was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.</p>

Power Monitor Dashboard | Custom Web Control | WinCC Unified & V8

<h3>Dynamic SVG</h3><h3>About Control Valve Symbol</h3><p>Control Valve Symbol is an interactive valve visualization for flow control systems. Designed for modern SCADA and HMI screens, it connects directly to your PLC tags for instant real-time updates. Ideal for piping and instrumentation diagrams, flow control panels.</p><h3>What You Can Configure</h3><p>With <strong>11 configurable properties</strong>, operators can change basic, status, color alarm colors to indicate equipment state, toggle visibility of icon alarm and icon lock elements, animate rotational elements like needles or pointers. All properties are directly bindable to PLC tags in TIA Portal — no coding required.</p><h3>Compatibility</h3><p>Works with <strong>WinCC Unified</strong> and <strong>WinCC V8</strong>. Simply drop the .svghmi file into your project and start configuring.</p><p>⚠️ <strong>AI-Generated:</strong> This dynamic SVG was automatically generated using AI. Please test and validate before deploying in production environments.</p><p>⚠️ <strong>AI-Generated:</strong> This dynamic svg was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.</p>

Control Valve Symbol | Dynamic SVG | WinCC Unified & V8

<h3>Dynamic SVG</h3><h3>About Pressure Transmitter</h3><p>The Pressure Transmitter is a high-fidelity Dynamic SVG component designed for professional industrial SCADA and HMI applications. Featuring a realistic metallic aesthetic with brushed steel and chrome effects, this control provides a high-performance visual representation of field instrumentation. It includes a detailed cylindrical housing, a threaded process connection, and a circular display head with a glass-covered LCD screen, ensuring your process dashboards look as professional as the hardware they represent.</p><h3>Key Features</h3><ul><li><strong>Realistic Visuals:</strong> Engineered with 4-stop linear gradients and radial highlights to simulate metallic depth and glass reflections.</li><li><strong>Dynamic LCD Display:</strong> Features a dedicated screen area for real-time pressure values with a customizable backlight.</li><li><strong>Integrated Isolation Valve:</strong> Includes an optional ball valve assembly for representing maintenance or isolation states.</li><li><strong>Industrial Aesthetics:</strong> Crisp 0.5px structural outlines and subtle drop shadows ensure clarity on both light and dark backgrounds.</li></ul><h3>Customization</h3><p>This control offers 12 adjustable properties for deep integration. You can modify the <strong>BasicColor</strong> and <strong>BezelInnerColor</strong> to match corporate standards, toggle the <strong>ShowGlassReflection</strong> for better visibility, and control the <strong>DisplayBackgroundColor</strong> to indicate alarm states. The <strong>ShowIsolationValve</strong> and <strong>ValvePosition</strong> properties allow for complex mechanical representations, while <strong>ShowMountingBolts</strong> and <strong>ShowProcessConnection</strong> provide flexibility for different installation types.</p><h3>Use Cases</h3><p>Perfect for oil and gas process monitoring, water treatment facility dashboards, chemical plant operator panels, and any industrial environment requiring precise pressure instrumentation visualization.</p><h3>Compatibility</h3><p>Fully compatible with <strong>WinCC Unified and WinCC V8</strong>. Simply import the dynamic SVG into your project and bind the properties directly to your PLC tags.</p><p><strong>Note:</strong> This dynamic SVG was generated using AI technology. It is recommended to verify all visual states and property bindings within your specific engineering environment before final deployment.</p><p>⚠️ <strong>AI-Generated:</strong> This dynamic svg was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.</p>
