About Linear Axis

Linear Axis is a Dynamic SVG that depicts a linear motion axis for machine and process visualization in SCADA and HMI applications. Import it into your WinCC Unified or WinCC V8 project and place it on any screen where axis or slide movement needs to be shown at a glance.

Key Features

• Clear axis graphic: A clean vector drawing that stays sharp at any zoom level and screen size.
• Single color control: The BasicColor property sets the base color of the graphic.
• Lightweight rendering: Vector-based SVG suited to operator panels and large overview screens.

Customization

The control exposes one configurable property, BasicColor, which defines the base color of the SVG element. Set it in the engineering tool to match your plant color scheme, or bind it to a PLC tag so the color can follow process conditions. No scripting is required.

Use Cases

Ideal for machine overview screens, motion sequence displays, and operator panels where axis context supports daily operation and fault diagnosis.

Compatibility

Works with WinCC Unified and WinCC V8. Add the graphic to your project's graphics library and insert it into any screen.
