About Can Seamer Top View

Can Seamer Top View is a Dynamic SVG that shows a can seamer from above, including the input can positions, three seaming stations and the output positions. Add it to your WinCC Unified or WinCC V8 project and bind its properties to PLC tags to animate the machine view in real time.

Key Features

• Roll motion: Roll1Offset and Roll2Offset move the two seaming rolls so operators can follow their position during the seaming cycle.
• Can flow visibility: Separate visibility properties show or hide the two input cans, three station cans and two output cans.
• Lens accent: LensColor sets the fill of the indicator lens so the machine state is visible at a glance.
• Vector quality: Scales cleanly on any panel resolution without loss of detail.

Customization

BasicColor sets the base color of the machine body. Bind Roll1Offset and Roll2Offset to position tags, and bind each visibility property to the matching PLC signal so cans appear exactly where the process places them. All eleven properties are configured in the engineering tool, with no coding required.

Use Cases

Ideal for can production line overviews, machine detail pages, operator panels and control room displays where operators need to follow can movement through the seamer.

Compatibility

Works with WinCC Unified and WinCC V8. Add the graphic to your project library, bind the properties and place it on any screen.

AI-Generated: This dynamic SVG was generated with AI assistance. Test and validate all bindings before deploying in production environments.

⚠️ AI-Generated: This dynamic svg was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.

## Current version: v1 (2026-10-23)
