<h3>Dynamic SVG</h3>
<p><h3>About Pilot Indicator Lamp</h3><p>The Pilot Indicator Lamp is a high-performance Dynamic SVG engineered for modern industrial SCADA and HMI environments. This versatile component provides a clear, high-contrast visual representation of machine states and process conditions, ensuring operators can identify system status at a glance. Designed for seamless integration, it allows for rapid deployment within WinCC Unified and WinCC V8 ecosystems by binding directly to PLC tags.</p><h3>Key Features</h3><ul><li><strong>Vector Precision:</strong> High-quality SVG artwork that remains sharp at any zoom level or resolution on industrial panels.</li><li><strong>Dynamic State Management:</strong> Integrated logic for real-time status visualization without complex scripting.</li><li><strong>Industrial Design Language:</strong> Clean, professional aesthetics that align with modern HMI design standards for reduced operator fatigue.</li></ul><h3>Customization</h3><p>The Pilot Indicator Lamp offers three primary properties for deep integration into your control logic:</p><ul><li><strong>BasicColor:</strong> Define the base aesthetic of the lamp assembly using the HmiColor property to match your corporate branding or specific functional categories.</li><li><strong>Status:</strong> A boolean-driven property that toggles the fill of the lamp-lens, providing immediate visual feedback of active or inactive states.</li><li><strong>Visible:</strong> Control the visibility of the entire lamp-assembly to create dynamic dashboards that show or hide elements based on machine configuration or user permissions.</li></ul><h3>Use Cases</h3><p>This component is ideal for indicating motor run/stop states, valve positions, safety interlock statuses, and general alarm conditions across manufacturing, water treatment, and energy sectors.</p><h3>Compatibility</h3><p>Fully compatible with <strong>WinCC Unified and WinCC V8</strong>. The artifact is delivered as a standard dynamic SVG, ready for immediate drag-and-drop use in your engineering environment.</p><p><strong>AI-Generated:</strong> This dynamic SVG was automatically generated using AI. Please test and validate its behavior within your specific hardware and software configuration before deploying in production environments.</p></p>
<p>⚠️ <strong>AI-Generated:</strong> This dynamic svg was automatically generated using AI technology. It may contain errors or unexpected behavior. Users are responsible for testing and validating before using in production environments.</p>


## Current version: v2 (2026-09-08)

AI control generator.

Pilot Indicator Lamp | Dynamic SVG | WinCC Unified & V8

Made with the HMIx AI Generator
