About Roller Conveyor
The Roller Conveyor is a high-fidelity Dynamic SVG designed specifically for modern industrial SCADA and HMI environments. This component provides a realistic and high-performance representation of material handling systems, allowing control engineers to visualize production flow with precision. Built for seamless integration into WinCC Unified and WinCC V8, it offers a professional aesthetic that adheres to modern industrial design standards while maintaining low CPU overhead on operator panels.
Key Features
- Dynamic Motion Simulation: Real-time animation of belt movement and drum rotation driven directly by PLC values for accurate process feedback.
- Structural Flexibility: Easily toggle between different conveyor styles to match the specific physical hardware on the plant floor.
- High-Performance Graphics: Vector-based SVG ensures crisp visuals at any zoom level, from small mobile devices to large high-resolution control room displays.
- Native Integration: Fully compatible with the hmi-bind syntax for effortless tag linking without the need for complex scripting.
Customization
The Roller Conveyor offers six specialized properties for deep integration into your automation project. Users can define the visual identity using BasicColor, BeltColor, and StripeColor to represent different material types, machine states, or branding requirements. For operational feedback, the BeltDisplacement and DrumRotation properties allow for smooth, tag-driven animations that reflect actual motor speeds and directions. Additionally, the RollersVisible boolean property enables engineers to switch between a smooth belt surface and a traditional roller-based design, providing versatility for various mechanical configurations.
Use Cases
This component is ideal for logistics centers, automated packaging lines, and manufacturing facilities where real-time tracking of material movement is critical. It is perfectly suited for overview screens, detailed equipment faceplates, and centralized control room dashboards.
Compatibility
Engineered for the Siemens ecosystem, this graphic is fully compatible with WinCC Unified and WinCC V8. Simply import the SVG into your library and bind the properties to your process tags to bring your HMI to life.
